Gate hardware and access control for professionals Product Catalog
locinoxusa.com Product Catalog
WHY LOCI Everything for your gate Gate closers 15 Tiger 19 Mammoth 20 Panther 22 Samson-2 23 Lion 24 Rhino 26 Verticlose-2 27 Serval 28 Caracal 29 Automation & Electronics 31 Magnus 36 Venus 37 Helios 40 Electromagnetic locks 47 Turnstiles 63 Locks 69 Keeps 109 Hinges 129 Drop bolts & Ground catchers 161 Gate catchers 171 Tools 175 Accessories 181 Marketing tools 215 2
INOX? Innovation Ease of installation At your service With stainless steel and nonferro metals as raw materials for its products, combined with the best surface treatment, our products maintain high standards and have a longer life cycle than cheaper alternatives. Locinox products are tested extensively by our R&D Department in the most extreme circumstances, up to a minimum of 500,000 movements before bringing it to the market. The modularity of our products allows you to choose from many different configurations. Locinox will assemble every possible configuration upon request. Moreover, our logistics guarantee a shipment of our catalogue products within 24h after your order. The products in our range are designed for maximum interchangeability. A large number of combinations is possible to ensure maximum flexibility according to your clients’ needs. Even after installation, our products can be easily adjusted and/or replaced. Enjoy 5 years of worry-free use on all our mechanical products. Go to locinoxusa.com/warranty and activate your additional 2 years warranty to enjoy 5 years of peace of mind. Because we care. A motivated team of engineers and prototypers works hard on a daily basis to further expand the Locinox range with new products. Our products guarantee fast installation and very solid fixation. Thanks to the special tools, the patented Quick-Fix and the Plug & Play design - installation happens in a blink of an eye. Our sales team is easy to reach and promptly replies by phone or e-mail in 7 supported languages. They will supply the correct product information and are happy to help you in choosing the right solution for the given situation. Weatherproof Custom assembly & packaging Industrial quality Modularity 5 Years of premium Warranty We continue to invest in our services and have turned our Loc-E-Shop into our most popular internal sales colleague, working 24/7 and processing nearly 90% of our orders every month. The Loc-E-Shop allows you to take full control of your orders at any time, wherever you are. Loc-E-Shop 3
LATEST INNOVATIO Motorized gate closer for pedestrian swing gates p.35 p.37 Venus Magnus Motorized hinge & gate closer in one for pedestrian gates 4
ONS “Challenging tradition with the power of innovation” p.123 Unilec Electric insert keep for insert locks Every innovation starts with an idea or suggestion. We keep an eye on the latest developments in the market and our sales team listens to the challenges you face every day. With innovation in their DNA, our engineers gather every piece of information and get to work with our core values at heart: product quality, easy installation, reliability and flexibility. 5
Vera Volta Battery powered code lock for insert locks Surface mounted lock with external battery powered keypad p.76 p.101 6
3006C-B 3006C 3006R-B 3006B 3006PAD-H 3006D Helios Handles A handful of new handle options Architectural outdoor lighting p.184 p.40 7
1 5 6 2 3 1 4 1 7 4 2 3 5 6 HELIOS CONE55 VERA + FIFTYLOCK + 3006PAD-H SFKU-V B-SAFE RHINO GBMU4D16 1 2 3 4 5 6 1 2 3 4 5 6 7 VERTICLOSE-2 U-SAFE HELIOS CONE85 BAR-I-90 DVK ELECTRADROP + SABO BEARING HINGE CONCEPT 8
1 3 6 1 2 3 5 2 5 4 1 2 3 4 5 1 2 3 4 5 6 TURNITEC VALENTINO + SH-KLQF VENUS-G U-SAFE GBMU4D16 HELIOS CUBE55 FIFTYLOCK + SFKU + 3006PAD B-SAFE VSF & EGS UNIWING BOLTONHD-4D4 TS 9
Thanks to a significant selection of products we have in stock, your order is guaranteed to be shipped within 24 hours of receipt. The miniload is the heart of our logistics at our Belgian HQ, with space for 90,000 bins. Thanks to a speed of 1,200 bins per hour, every product reaches the packaging line within 2 minutes. 24 hours Miniload LOGISTICS 10
This is where your all-in-one sets are assembled in durable, weatherproof boxes. From locks to drop bolts or customised configurations, each set includes everything you need for a quick and seamless installation Set assembly S 11
By following the latest market trends and listening to your daily challenges, our dedicated team of engineers gets to work. Guided by our core values—quality, reliability, flexibility, and easy installation—they develop innovative solutions designed to serve you better. To guarantee top performance, we test every product in extreme conditions. From salt spray and climate simulation to load testing, we make sure they perform in every situation. Product development Test chamber RESEARCH DEVELOPM 12
This is where your future solutions are brought to life. Our prototyping team works side by side with R&D, only separated by a glass wall, to develop a product that exceeds your expectation. Prototyping H & MENT[HQ BELGIUM] 13
14 GATE CLOSERS
Gate closers Hydraulic gate closers will transform any gate into a self-closing solution. Comfort, safety and peace of mind are guaranteed thanks to pure hydraulic power. High quality components ensure Locinox closers to be 100% weatherproof, maintenance-free and extremely durable. A constant and consistent functioning is guaranteed during an ice cold winter or a sweltering summer. The unique concept ensures an easy and efficient fixation thanks to the patented Quick-Fix system. Moreover, closing speed and final snap can be adjusted very precisely and 100% to your customers’ wishes. 15 GATE CLOSERS
A consistent closing speed From freezing winter to sizzling summer. If your gate closes too slow, children or pets could sneak through. If your gate closes too fast, it might become a problem for wheelchair users. A loud slamming gate is not only annoying for you or your neighbors, it’s also harmful for your gate. The Active Thermal System, our own cutting-edge development, guarantees a constant closing speed, regardless of the outside temperature. Adjust speed and final snap precisely Some customers prefer their gate to close slowly, while others want it to go a little faster. No problem! All of our hydraulic gate closers can easily be adjusted in a matter of seconds to the wishes of your customers. The final snap allows the gate to speed up a little at the end: this way, you are reassured the gate is properly closed. The final snap can easily be adjusted to any need. Functions comfortably The in-house developed High-Helix screws guarantee a consistent functionality and ensure a comfortable closing speed for the elderly or disabled. Dust- & waterproof Our gate closers are equipped with rotary seals. These seals protect the gate closers from dirt and dust particles intruding the mechanism,assuring your customers of worryfree functioning for many years to come. Closes every time The powerful torsion spring guarantees the necessary closing force. Therefore, your gate will always close: unaffected by strong winds, the width of your gate wing or the outside temperature. You can rest assured. 100% Protected The aluminum housing guarantees full protection against any weather conditions. The housing is windproof, frostfree and dust- & waterproof, allowing your gate closer to function perfectly Cutting edge self-closing technology 16
10s 20s 30s 40s RHINO LION* PANTHER SAMSON 2* VERTICLOSE 2 Self-closing Final snap 330 lbs 165 lbs 4 ft 3 ft 0 ft 5 ft 6-1/2 ft Recommended gate width *Fits chain link with optional brackets OPENING ANGLE NEW FIT RETRO FIT GATE CLOSER & HINGE IN ONE USE WITH EXISTING HINGES ALL LOCINOX GATE CLOSERS SAMSON 2 PANTHER Max. 150° depending on position of hinge and gate closer Depending on position of hinge and gate closer OPEN & CLOSE 180° OPEN & CLOSE 150° OPEN & CLOSE 120° SERVAL* CARACAL* TIGER* MAMMOTH180* MAMMOTH HD* 330 lbs 440 lbs 165 lbs 132 lbs Temperature resistance Find the perfect gate closer Temperature in °F Tested at 90° opening position Locinox Competition Comfort issue Safety issue Perfect comfort and safety TOO FAST TOO SLOW IDEAL FUNCTIONING Closing time 158° 140° 104° 68° 32° -22° -4° 17
Locinox gate closers, why? Exceptional precise adjustment of speed & final snap for your comfort Efficient fast & easy installation Child & pet friendly 100% hydraulic green & maintenance free Safe for wheelchair users Durable tested for 500,000 movements A silent opening & closing Extreme weatherproof constant closing speed Vandal proof design 18
19 GATE CLOSERS 4 FT 165 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX ROSPA ADA PMR COLOR OPTIONS SILV 9005 3/4” 1-1/8” 2-3/4” Ø9/16” (4x) 4-1/4” 2-1/4” 1-7/8” 10-3/8” 2-5/8” 2-1/8” 1-3/4” 2” 1” 4-1/4“ 9/16” 13/16” TIGER (Patented) Compact 180° hydraulic gate closer and hinge for gates up to 165 lbs 180° self-closing hydraulic hinge with precise adjustments on speed and final snap. The aluminum powder coated housing and unique high-tech components allow the Tiger to function perfectly in any weather situation. We highly recommend the Tigerdrill for an even more efficient installation. The Puma hinge is included. ORDER CODE TIGER Hydraulic gate closer and Puma 180° hinge for gates up to 165 lbs RECOMMENDED PRODUCTS TIGERDRILL P. 178 CLB-TIGER P. 201 SPECIFICATIONS • 180° self-closing hinge with patented hydraulic damping • Compact design with high quality components • Weatherproof aluminum housing designed for exterior use • Patented hydraulic damping - consistent closing speed, regardless of temperature • For left and right turning gates • Fast and easy fixation with Quick-Fix bolts • Installation gap 7/16" up to 1" (5/8" adjustability) • 3/4" vertical adjustability • ADA compliant (< 5 lbs; max 16 Nm) from gate widths of 3ft. or more
20 GATE CLOSERS 5 FT 330 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX ADA PMR COLOR OPTIONS SILV 9005 5-1/2” 16” 2-3/8” 4-3/8” 5-1/2” Ø 9/16” (8x) 1-5/8” 2-3/8” 4” 1-5/8” 4-3/8” 2” 2” 3/4” 3/4” 13/16” 13/16” MAMMOTH180 (Patented) Heavy duty 180° hydraulic gate closer and hinge for gates up to 330 lbs Sleek and powerful self-closing hinge for 180° gate situations. The Mammoth is perfectly fit for gates up to 330 lbs. It is equipped with a double bearing for exceptional functionality. An Active Thermal System guarantees a constant closing speed, unaffected by weather conditions. The Dino hinge is included. ORDER CODE MAMMOTH180 Heavy-duty 180° hydraulic gate closer and hinge-in-one for gates up to 330 lbs RECOMMENDED PRODUCTS CLB-MAMMOTH P. 201 SPECIFICATIONS • 180° self-closing double bearing hinge with adjustable closing speed and final snap • Robust yet stylish design with high quality components • Weatherproof aluminum housing designed for exterior use • Consistent closing speed thanks to patented hydraulic damping • ADA compliant (< 5 lbs; max 16 Nm) from gate widths of 3ft. or more • Vandal and tamper proof • For left and right handed gates • Fast and easy installation with Quick-Fix • Installation gap 9/16 min up to 1-3/8" max (ornamental); 9/16" adjustability in height
21 GATE CLOSERS 6-1/ 2 FT 440 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX ADA PMR COLOR OPTIONS SILV 9005 5-1/2” 5-1/2” 5-1/2” 5-1/2” 2-3/8” 2-3/8” 4-5/16” 4-5/16” 2-1/16” 2-1/16” 8-7/16” 15-3/4” 8x Ø 9/16” 13/16” 13/16” MAMMOTH-HD (Patented) Ultra heavy duty 180° hydraulic gate closer and hinge for gates up to 440 lbs This heavy-duty gate closer and hinge-in-one is fit to close the heaviest gates. The combination of the hydraulically damped Mammoth with the powerful self-closing Raptor hinge is the perfect solution for closing gates weighing up to 440 lbs and 6-1/2 ft. wide. Both hinges are equipped with double bearings for extremely smooth functioning. The Active Thermal System guarantees a constant closing speed, unaffected by weather conditions. The Raptor hinge is included. ORDER CODE MAMMOTH-HD Heavy-duty 180° hydraulic gate closer and hinge-in-one for gates up to 440 lbs SPECIFICATIONS • 180° self-closing double bearing hinge with adjustable closing speed and final snap • Robust yet stylish design with high quality components • Weatherproof aluminum housing designed for exterior use • Consistent closing speed thanks to patented hydraulic damping • ADA compliant (< 5 lbs; max 32 Nm) from gate widths of 4.4ft. or more • Vandal and tamper proof • For left and right handed gates • Fast and easy installation with Quick-Fix • Installation gap 9/16 min up to 1-3/8" max (ornamental); 9/16" adjustability in height
22 GATE CLOSERS 5 FT 330 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX ROSPA ADA PMR COLOR OPTIONS 9005 14-3/8” 5-1/2” 4-3/16” 5-5/8” 6-11/16” 5-5/8” 4-3/16” 14-3/8” 6-11/16” 5-1/2” PANTHER All-round hydraulic gate closer for wall and post mounting Versatile, easy-to-install and compact gate closer designed specially for wall and post situations. Panther is installed above the gate or between two pillars and can precisely be adjusted to anyone's wishes. The guaranteed closing force over the full 120° opening angle results in a worry free use, regardless of the weather conditions. The aesthetic and scratch free anodized housing ensures a very long life cycle. ORDER CODE PANTHER All-round hydraulic gate closer for wall and post mounting, for gates up to 330 lbs RECOMMENDED PRODUCTS GATESTOP P. 210 1034ROLL-HDG P. 138 RAIL-FIT P. 202 SPECIFICATIONS • Gate closer for wall-mounting with adjustable closing speed and final action • Consistent closing speed thanks to patented hydraulic damping • Robust yet stylish design with high quality components • Weatherproof, scratch resistant and corrosion free anodized aluminum housing • Designed to be installed above the gate • Integrated pretension for extremely smooth installation • Closing force over the full 120° opening angle • Recommended with Gatestop
23 GATE CLOSERS 2” 1-3/8” 1-5/8” 4” 1-3/8” Ø9/16” 1-1/8” 1-3/8” 3-1/4” 1-3/4” Ø9/16” 1-1/8” Min. 3” 2” 3-3/8” 2-7/8” RECOMMENDED PRODUCTS SB P. 200 SILV 6-1/ 2 FT 330 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX COLOR OPTIONS ORDER CODE SAMSON-2 Hydraulic gate closer for gates up to 300 lbs SAMSON-2 (Patented) Hydraulic retrofit gate closer for wide gates up to 330 lbs Simple installation and versatility make it the perfect fit for larger gates. Samson-2 is a polyvalent hydraulic gate closer developed with high quality components for an exceptional long life span. Temperature changes do not affect the smooth and constant functionality. The set of mounting brackets that are delivered with the closer make Samson-2 fit for any gate. Also fitted for chain link fences. SPECIFICATIONS • Hydraulic gate closer up to 150° with adjustable closing speed and final action • Specially developed for outdoor use: industrial quality • Weatherproof, scratch resistant and corrosion free anodized aluminum housing • Consistent closing speed thanks to patented hydraulic damping • Fast and easy fixation with Quick-Fix bolts • For left and right turning gates • ADA compliant (< 5 lbs; max 25 Nm) from gate widths of 4ft. or more
24 GATE CLOSERS Ø9/16” (4x) Ø9/16” (4x) 1-3/16” 13-3/4” 12-5/8” MAX 6-7/8” 12-5/8” 2” 1-3/16” 12-5/8” 13-9/16” 20 Ø2-5/16” 90° 180° 2-3/16” 2-5/8” 1-3/16” 12-1/16” RECOMMENDED PRODUCTS LION-VTC-DRILL P. 177 SHELL-LION P. 198 RAIL-FIT P. 202 3018LION P. 198 SILV 9005 4 FT 165 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX ADA PMR COLOR OPTIONS ORDER CODE LION Compact hydraulic gate closer for any gate situation LION (Patented) Compact 90° or 180° retrofit gate closer for gates up to 165 lbs The attractive and compact Lion gate closer is unique in its kind. This hydraulic allrounder is fit for every possible gate situation. Moreover, both 90° and 180° railsets are included in the package, allowing for more flexibility on site. The anodized aluminum housing combines a handsome look with a durable and spotless functioning for many years. Choose the Lion-VTC Drill for an even faster installation. SPECIFICATIONS • 180° retrofit gate closer with adjustable closing speed and final action • Railset included for 90° and 180° situations (depending on hinges used) • Weatherproof, scratch resistant and corrosion free anodized aluminum housing • Compact design with high quality components • Consistent closing speed thanks to patented hydraulic damping • For left and right handed gates • Integrated pretension for extremely smooth installation • ADA compliant (< 5 lbs; max 16 Nm) from gate widths of 3ft. or more
25 GATE CLOSERS 5 FT 330 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX ADA PMR COLOR OPTIONS SILV 9005 = = Ø9/16” (2x) 4-5/8” 11” 19-1/16” 2-1/2” Ø3/16” (2x) 2-7/8” 1-3/16” MIN. 1-3/16” MAX. 1-3/8” RHINO (Patented) Elegant 180° gate closer with direct connection to the hinge Transform your 180° hinge into a self-closing solution thanks to our Rhino hydraulic gate closer. The direct connection to the Locinox hinge guarantees the discreet look and efficient transmission of the energy required to close the gate perfectly. The anodized aluminum housing ensures a durable and smooth operation in any weather. The Rhinodrill jig guarantees an extremely efficient installation. ORDER CODE RHINO Hydraulic gate closer for gates up to 300 lbs RECOMMENDED PRODUCTS RHINODRILL P. 178 1034ROLL-HDG P. 138 SHELL-RHINO-VTC P. 199 SPECIFICATIONS • 180° self-closing double bearing hinge with adjustable closing speed and final snap • Consistent closing speed thanks to patented hydraulic damping • Weatherproof, scratch resistant and corrosion free anodized aluminum housing • Fits 180° hinges M16 & M20 (GBMU, GBMU4D) & M16 (BOLTON4D) • Bearing eyebolt is recommended (1034ROLL-M16) • Integrated pretension for extremely smooth installation • ADA compliant (< 5 lbs; max 20 Nm) from gate widths of 3ft. or more
26 GATE CLOSERS 5 FT 330 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° ADA PMR COLOR OPTIONS SILV 15-5/8” 12-5/8” 13-3/4” 3” 15-5/8” 12-5/8” 11-7/8” 2” 3” 1-1/8” 90° 180° 12-5/8” 1-1/8” VERTICLOSE-2-WALL (Patented) 90° or 180° hydraulic gate closer for wall-mounted gates up to 330 lbs The Verticlose-2-Wall gate closer has been specifically designed for wall mounting where the gate closer itself is positioned at a 90° position in relation to the gate. The specially designed arm turns around the wall or post, ensuring a large opening angle. The aesthetic anodized aluminum gate closer with high-tech internal components ensures an exceptionally long life span. ORDER CODE VERTICLOSE-2-WALL Powerful and all-round hydraulic gate closer for wall mounting RECOMMENDED PRODUCTS LION-VTC-DRILL P. 177 SHELL-RHINO-VTC P. 199 RAIL-FIT P. 202 SPECIFICATIONS • Gate closer for wall-mounting with adjustable closing speed and final action • Specially designed arm for wall mounting while guaranteeing a big opening angle • Weatherproof, scratch resistant and corrosion free anodized aluminum housing • Robust yet stylish design with high quality components • Integrated pre-tension for extra smooth installation • Consistent closing speed thanks to patented hydraulic damping • Firmly fixed thanks to patented Quick-Fix system • ADA compliant (< 5 lbs; max 25 Nm) from gate widths of 4ft. or more
27 GATE CLOSERS 5 FT 330 LBS YEAR 3 WARRANTY CYCLES 500 K -22° +158° QUICK-FIX ADA PMR COLOR OPTIONS SILV 9005 11” Ø 9/16” Ø 1/4” Ø 9/16” Ø 9/16” 2” 3-3/4” 11” Ø 1/4” 90° 180° 12-5/8” Ø 9/16” Ø 9/16” Ø 9/16” VERTICLOSE-2 (Patented) Heavy duty 90° or 180° retrofit hydraulic gate closer for gates up to 330 lbs The Verticlose-2 gate closer is top-of-the-range within the Verticlose product series. It is extremely multifunctional and possesses excellent features, which makes Verticlose-2 a perfect fit for both 90° and 180° hinge situations. The integrated pre-tension and continuous adjustability of speed and final snap, combined with our Quick-Fix mounting system, guarantee a quick and efficient installation. The aesthetic anodized aluminum gate closer with high-tech internal components ensures an exceptionally long life span. We highly recommend the Lion-VTC Drill for an even more efficient installation. ORDER CODE VERTICLOSE-2 Powerful and all-round hydraulic gate closer for 90° and 180° hinges RECOMMENDED PRODUCTS LION-VTC-DRILL P. 177 SHELL-RHINO-VTC P. 199 RAIL-FIT P. 202 SPECIFICATIONS • Micro adjustment of speed and final snap • Railset included for 90° and 180° situations (depending on hinges used) • Weatherproof, scratch resistant and corrosion free anodized aluminum housing • Robust yet stylish design with high quality components • Integrated pre-tension for extra smooth installation • Consistent closing speed thanks to patented hydraulic damping • Firmly fixed thanks to patented Quick-Fix system • ADA compliant (< 5 lbs; max 25 Nm) from gate widths of 4ft. or more
28 GATE CLOSERS 4 FT LBS 132 YEAR 3 WARRANTY CYCLES 500 K -22° +140° ROSPA ADA PMR 4-5/8” 5-9/16” Ø7/32”(x8) 4” 4” 1-3/16” 1” 1” 2-5/8” 2-5/8” Ø5,5 (x8) 4-5/8” 5-9/16” 2-1/16” 2-1/3” 1-1/6” 2-1/16” 2/6” 1/29” 1-3/16” 13/16” 13/16” SERVAL 180° Spring hinge mounted with self-drilling screws The Serval is a compact spring hinge with force adjustability. The fiberglass reinforced polyamide housing protects the high-tech internal components, allowing for perfect functionality in all weather conditions. Its 13/16" vertical and horizontal adjustability ensures an easy and flexible installation. Firmly fixed with self-drilling screws - no welding required. Suitable for installation on square and round frames. ORDER CODES SERVAL-SD-R 180° Spring hinge mounted with self-drilling screws for round profiles SERVAL-SD-K 180° Spring hinge mounted with self-drilling screws for square profiles RECOMMENDED PRODUCTS FORTIMA P. 86 GUARDIMA P. 87 NOSTEP P. 203 CARACAL P. 29 SPECIFICATIONS • 180° spring hinge with force adjustability • Fiberglass reinforced polyamide housing • For left and right turning gates • Fast and easy fixing with self-drilling screws • Force adjustability from 2 up to 7 Nm (at closed position) • Easy to open: Max. 10 Nm • 13/16" horizontal and vertical adjustability • Use of NOSTEP anti-climb device is recommended
29 GATE CLOSERS 4 FT LBS 132 YEAR 3 WARRANTY CYCLES 500 K -22° +140° ROSPA ADA PMR 4-5/8” 5-3/5” 2-1/16” 3/4” 3/4” 7-1/8” 2-1/16” 4-5/8” CARACAL (Patented) Hydraulic 180° gate closer and hinge Aesthetic 180° gate closer with adjustable closing speed. The glassfibre reinforced PA housing protects the high-tech internal components, allowing for a perfect functioning in all weather circumstances. Its 13/16" vertical and horizontal adjustability ensures an easy and flexible installation. Firmly fixed with self-drilling screws - no welding required. Suitable for installation on square and round frames. Caracal is a perfect fit for swimming pools, playgrounds, parks and garden gates. Including Serval self closing hinge. ORDER CODE CARACAL-SD-K Hydraulic 180° gate closer and hinge mounted with self-drilling screws for square profiles RECOMMENDED PRODUCTS FORTIMA P. 86 GUARDIMA P. 87 NOSTEP P. 203 CLB-CARACAL P. 201 SPECIFICATIONS • Automatic 180° closure with adjustable closing speed • Fiberglass reinforced PA housing • Patented hydraulic damping - consistent closing speed, regardless of temperature • For left and right turning gates • Fast and easy fixing with self-drilling screws • 13/16" horizontal and vertical adjustability • Easy to open: Max. 11 Nm • For installation on round frame: CLB-CARACAL to be ordered additionally
30 AUTOMATION & ELECTRONICS
Automation & electronics Automation has become a fundamental factor in the fence & gate industry. Locinox offers a wide range of solutions to manufacture user-friendly smart gates. 31 AUTOMATION & ELECTRONICS
VENUS Motorized gate closers For pedestrian swing gates Motorized gate closers combine power and precision with smart technology, specifically designed for outdoor pedestrian gates. They ensure maximum safety by always closing, no matter the weather conditions, and offer comfort for all users. Innovative features like push & go technology and integration with access control provide added convenience and security. A reliable and modern solution for every situation. Smooth and quick access The push-and-go feature ensures that you already activate the gate opener with a gentle push. The gate automatically opens on its own and closes automatically afterwards. Handy if your hands are full or can’t exert as much force. Comfort for all Are you approaching the gate in a wheelchair, pushing a bike or carrying heavy shopping bags? Thanks to the pre determined waiting and closing times set by the installer as desired, the gate closer takes these situations into account. Safety above all Thanks to its integrated obstacle detection feature, the gate closer will reopen the gate and ensure it is fully closed only when everything and everyone has safely passed through. 32
MAGNUS Easy Installation Drill a few holes to mount with Quick-Fix and connect the plug-and-play wiring, and the gate closer is ready to go. Brushless The brushless motor operates quietly and smoothly, with minimal friction and wear. This guarantees a long lifespan, even under intensive and unpredictable use. Reversible The reversible motor allows for easy manual intervention even during automatic opening or closing. This prevents blockage or damage and ensures smooth operation. Easy configuration An intuitive application will guide you through the installation process, providing step-by-step instructions. All-in-one All the components, including the revolutionary steel gearbox, motor and motor control and all electronics, are enclosed within a compact aluminium housing. Vandal proof The motor’s high backdrivability protects the electronics against any physical impact. Moreover, the WiFi connection can only be accessed after opening the case with your own key. 33
34 AUTOMATION & ELECTRONICS
35 AUTOMATION & ELECTRONICS NEW 1400 MM 4.6 FT YEAR 2 WARRANTY QUICK-FIX 24V DC IP 56 SELF-CLOSING GATE ADA COLOR OPTIONS SILV 9005 Ø9/16”(14x) 1-9/16” 5-1/8” 10-1/4” 2-3/8” 4-5/8” 3-15/16” 2-3/4” 2-15/16” 5-1/2” 15-11/16” 11-13/16” Ø1-9/16” 5-1/16” 3-1/4” 1-15/16” 2-3/16” 4-13/16” 3-3/16” Ø13/16” MAGNUS (Patent pending) Motorized hinge & gate closer in one for pedestrian gates Coming Soon. MAGNUS is a motorised hinge and gate closer in one, designed for the automation of pedestrian gates. The brushless and reversible motor is insensitive to unpredictable pedestrian behaviour, and operates in low-energy mode. The settings and access control can be configured via an intuitive app. Includes lower hinge and compact connection box. ORDER CODE MAGNUS Motorized gate closer & hinge in one for pedestrian gates RECOMMENDED PRODUCTS SLIMSTONE-2 P. 38 MODULEC-SA P. 112 MAGMAG P. 48 MODULEC-SF P. 124 SPECIFICATIONS • Motorized gate closer with integrated electronics • 75 Nm torque • Fits on post profiles from 2 3/8" and gate profiles from 1 9/16" • Steel gear box • Anodized aluminium cover • Fast and easy fixation with Quick-Fix bolts • Conforms to UL/cUL 325 standard for automatic operators, tested by ETL • Input main power supply: 110V AC to 240V AC • Motor voltage: 24V DC • External connection box with 3 inputs and 3 outputs (Max. 48W, 24V DC) • Automated obstacle detection with reverse function • Brushless motor: long lifespan and intensive usage • Reversible motor with backdrivability for easy manual use - to be combined with a lock • 6-1/2ft cable between motor and connection module • Compact and vandal-proof design • Configuration via app • Tested up to 500 000 cycles • EN 16005 Compliant
36 AUTOMATION & ELECTRONICS 11-13/16" 1-5/16" 11-13/16" 12-5/8" 14-3/16" VENUS-ARM-S Sliding arm to install Venus Accessory to install the Venus with any type of hinge. SPECIFICATIONS ORDER CODE VENUS-ARM-S Sliding arm to install Venus • Compatible with Venus • Available in two colors: RAL 9005 & SILV 11-13/16" 11-13/16" VENUS-ARM-A Articulated arm for Venus installation Accessory to install the Venus in situations with distances up to 9 13/16" inches between the motor and hinge axes. SPECIFICATIONS ORDER CODE VENUS-ARM-A Articulated arm for Venus installation • Compatible with Venus • Available in two colors: RAL 9005 & SILV 11/16” 3-1/8” 9-3/16” 10-3/4” VENUS-ARM-G Arm to install Venus with 180° hinges Accessory to install the Venus with 180° hinges. Compact design that supports large opening angles. SPECIFICATIONS ORDER CODE VENUS-ARM-G Arm to install Venus with 180° hinges • Compatible with Venus • Available in two colors: RAL 9005 & SILV
37 AUTOMATION & ELECTRONICS 1400 MM 4.6 FT 100 KG 220 LBS YEAR 2 WARRANTY -22° +158° QUICK-FIX 24V DC IP 54 SELF-CLOSING GATE COLOR OPTIONS SILV 9005 3-1/8" 3-1/8" 12-5/8" 20-1/16" 14-3/16" VENUS (Patent pending) Motorized gate closer for pedestrian swing gates The Venus is a plug-and-play motorized gate closer for pedestrian swing gates. The compact all-in-one gate operator can easily be installed on any type of post and hinge thanks to 3 different arm types. The innovative motor's performance remains unaffected by manual force. When combined with access control, the Venus also works as a low-energy gate opener. ORDER CODES VENUS-S Motorized gate closer with articulated arm for pedestrian swing gates VENUS-A Motorized gate closer with compact arm for pedestrian swing gates with 180° hinges VENUS-G Motorized gate closer with sliding arm for pedestrian swing gates COMPATIBLE PRODUCTS SLIMSTONE-2 P. 38 MODULEC-SF P. 124 VENUS-ADAPTERPLATE P. 197 B-MAG P. 53 SPECIFICATIONS • Motorized gate closer with integrated electronics • 150 Nm torque • Fits on 3 2/16" profiles • For pedestrian gates up to 4.6 ft wide and 220 lbs • Steel gear box • Anodized aluminium cover • 3 different arm options for installation • Fast and easy installation with Quick-Fix • Conforms to UL/cUL 325 standard for automatic operators, tested by ETL • Input main power supply: 110V AC to 240V AC • 3 inputs and 3 outputs (Max. 48W, 24V DC) • Integrated warning light • Automated obstacle detection with reverse function • Brushless motor: long lifespan and intensive usage • Reversible motor with backdrivability for easy manual use - to be combined with a lock • Compact and vandal-proof design • EN 16005 Compliant • Configuration via app • Tested up to 500 000 cycles
38 AUTOMATION & ELECTRONICS COLOR OPTIONS SILV 9005 COMPATIBLE PRODUCTS SWITCHSTONE-STD P. 61 MODULEC-SA P. 112 LIKQU2 P. 81 INTRALEC P. 124 15/16” 5-3/8” 2-1/8” 2” 4-17/32” Ø9/16” (3x) SLIMSTONE-X Weather resistant keypad with external relays The durable and robust SlimStone-X keypad has been developed to work with the SwitchStone-STD. When both combined, the SlimStone-X ensures maximum security against burglary thanks to 2 external relays, both with a common, Fail Open and Fail Close contact. The keypad is easy in installation and configuration, and is developed and tested for use in the most extreme weather conditions (IP68). ORDER CODE SLIMSTONE-X Strong, frost-free and watertight keypad SPECIFICATIONS • IP68 rated - Extremely resistant to water and dust • Long range secure 2-wire communication with SwitchStone-STD, distance up to 330 yards • Auto back up functionality • External relay offers additional protection • Highly resistant stainless steel push buttons tested for 1,000,000 pushes and more • Easy programming of up to 400 user codes • Smart heating element guarantees frost-free use • Tested from -22°F to 185°F • Consumption: 1,5 W (> 41°F) + 12 W at max heating (< -13°F) COLOR OPTIONS SILV 9005 COMPATIBLE PRODUCTS MODULEC-SA P. 112 INTRALEC P. 124 B-MAG P. 53 LIKQU2 P. 81 15/16” 5-3/8” 2-1/8” 2” 4-17/32” Ø9/16” (3x) SLIMSTONE-2 Weather resistant keypad with 2 integrated relays The SlimStone-2 keypad has 2 integrated relays, with a Fail Open and Fail Close contact. These make it easy to connect to Locinox and third-party automation products. This keypad with integrated LED lighting is strong and extremely weather resistant, thanks to integrated heating and IP68 waterproof rating. ORDER CODE SLIMSTONE-2 Sturdy, frost-free and weather resistant keypad with 2 integrated relays SPECIFICATIONS • IP68 rated - Extremely resistant to water and dust • Aluminum vandal-proof housing with scratch-resistant textured lacquer • Highly resistant stainless steel push buttons tested for 1,000,000 pushes and more • Easy installation and configuration • Easy programming of up to 100 user codes • Voltage: 10 up to 26 V AC/DC • Current: 1.0 A (with heating) • 2 integrated switching relays: 2 x NO - 2 x NC - 2 x COM (Max. 2A, 60W, 26V AC/DC) • Consumption: 1,5 W (> 41°F) + 12 W at max heating (< -13°F)
39 AUTOMATION & ELECTRONICS
CONE ARCO CUBE HEPTA HELIOS architectural outdoor lighting Perfect harmony between functionality and aesthetics With a complete range of 7 different models, you can design the outdoor space entirely according to your preferences. Choose from the standard colors of black, silver, anthracite and bronze or paint the lights in any color of your choice. TIP • Coat the housing together with the gate for a stunning result. 40
41 AUTOMATION & ELECTRONICS NEW 1” 1” 3-9/16” 3-15/16” 2-3/16” 3-3/8” 2-5/8” 3-7/16” Ø9/16” (2x) CONE55 CONE85 COLOR OPTIONS ALUM SILV 9005 7016 BRON YEAR 2 WARRANTY ALU QUICK-FIX IP 65 CONE (Patent pending) Architectural conical wall lighting Upgrade your gate installations and surrounding areas with a warm and atmospheric touch with this conical wall lighting from the HELIOS portfolio. The high-quality aluminum housing guarantees durability in all weather conditions. Choose from different standard colors or personalize the uncolored variant with any powder coating of your choice. These lights are available in 2-3/16" or 3-3/8" widths and 12-24V DC connection, ideally combined with POWERSTONE. ORDER CODES CONE55-230V 2-3/16" mm wide, 230V AC CONE55-DC 2-3/16" mm wide, 12V DC / 24V DC CONE85-230V 3-3/8" mm wide, 230V AC CONE85-DC 3-3/8" mm wide, 12V DC / 24V DC POWERSTONE P. 60 DC-POWER-12V-20W P. 61 DC-POWER-24V-25W P. 61 RECOMMENDED POWER SUPPLIES SPECIFICATIONS • Available in various colors or customizable via powder coating • Width: 2-3/16" or 3-3/8" • Color temperature: 2700K • IP65 • Power consumption: max. 3W (12-24V DC) • Plug & play installation with WAGO connectors • Lifetime: 50,000 hours while maintaining 80% of initial brightness • Easy installation with standard tools and supplied Hex keys • Brightness: 300 lm
42 AUTOMATION & ELECTRONICS NEW 1” 1” 2-3/4” 2-3/16” 2-1/2” 3-1/16” 2-15/16” 2-3/4” Ø9/16” (2x) CUBEE55 CUBE75 COLOR OPTIONS ALUM SILV 9005 7016 YEAR 2 WARRANTY ALU QUICK-FIX IP 65 CUBE (Patent pending) Architectural cubic wall lighting Upgrade your gate installations and surrounding areas with a warm and atmospheric touch with this cubic wall lighting from the HELIOS portfolio. The high-quality aluminum housing guarantees durability in all weather conditions. Choose from different standard colors or personalize the uncolored variant with any powder coating of your choice. These lights are available in 2-3/16" and 2-15/16" widths and 12-24V DC connection, ideally combined with POWERSTONE. ORDER CODES CUBE55-230V 2-3/16" mm wide, 230V AC CUBE55-DC 2-3/16" mm wide, 12V DC / 24V DC CUBE75-230V 2-15/16" mm wide, 230V AC CUBE75-DC 2-15/16" mm wide, 12V DC / 24V DC POWERSTONE P. 60 DC-POWER-12V-20W P. 61 DC-POWER-24V-25W P. 61 RECOMMENDED POWER SUPPLIES SPECIFICATIONS • Available in various colors or customizable via powder coating • Width: 2-3/16" or 2-15/16" • Power consumption: max. 3W (12-24V DC) • Color temperature: 2700K • IP65 • Plug & play installation with WAGO connectors • Lifetime: 50,000 hours while maintaining 80% of initial brightness • Easy installation with standard tools and supplied Hex keys • Brightness: 300 lm
43 AUTOMATION & ELECTRONICS NEW 1” 1” 2-3/4” 2-3/16” 2-1/2” 3-1/16” 2-15/16” 2-3/4” Ø9/16” (2x) ARCO55 ARCO85 COLOR OPTIONS ALUM SILV 9005 7016 YEAR 2 WARRANTY ALU QUICK-FIX IP 65 ARCO (Patent pending) Architectural arched wall lighting Upgrade your gate installations and surrounding areas with a warm and atmospheric touch with this arched wall lighting from the HELIOS portfolio. The high-quality aluminum housing guarantees durability in all weather conditions. Choose from different standard colors or personalize the uncolored variant with any powder coating of your choice. These lights are available in 2-3/16" or 2-15/16" widths and 12-24V DC connection, ideally combined with POWERSTONE. ORDER CODES ARCO55-230V 2-3/16" mm wide, 230V AC ARCO55-DC 2-3/16" mm wide, 12V DC / 24V DC ARCO75-230V 2-15/16" mm wide, 230V AC ARCO75-DC 2-15/16" mm wide, 12V DC / 24V DC POWERSTONE P. 60 DC-POWER-12V-20W P. 61 DC-POWER-24V-25W P. 61 RECOMMENDED POWER SUPPLIES SPECIFICATIONS • Available in various colors or customizable via powder coating • Width: 2-3/16" or 2-15/16" • Power consumption: max. 3W (12-24V DC) • Color temperature: 2700K • IP65 • Plug & play installation with WAGO connectors • Lifetime: 50,000 hours while maintaining 80% of initial brightness • Easy installation with standard tools and supplied Hex keys • Brightness: 300 lm
44 AUTOMATION & ELECTRONICS NEW 1” 3-1/8” 2-15/16” 1-15/16” Ø9/16” (2x) HEPTA75 COLOR OPTIONS ALUM SILV 9005 7016 YEAR 2 WARRANTY ALU QUICK-FIX IP 65 HEPTA (Patent pending) Architectural trapezoidal wall lighting Upgrade your gate installations and surrounding areas with a warm and atmospheric touch with this trapezoidal wall lighting from the HELIOS portfolio. The high-quality aluminum housing guarantees durability in all weather conditions. Choose from different standard colors or personalize the uncolored variant with any powder coating of your choice. These lights are 2-15/16" wide and available for 12-24V DC connection, ideally combined with POWERSTONE. ORDER CODES HEPTA75-230V 2-15/16" mm wide, 230V AC HEPTA75-DC 2-15/16" mm wide, 12V DC / 24V DC POWERSTONE P. 60 DC-POWER-12V-20W P. 61 DC-POWER-24V-25W P. 61 RECOMMENDED POWER SUPPLIES SPECIFICATIONS • Available in various colors or customizable via powder coating • Width: 2-15/16" • Power consumption: max. 3W (12-24V DC) • Color temperature: 2700K • IP65 • Plug & play installation with WAGO connectors • Lifetime: 50,000 hours while maintaining 80% of initial brightness • Easy installation with standard tools and supplied Hex keys • Brightness: 300 lm
45 AUTOMATION & ELECTRONICS 3-1/2” 3/4” 1-1/8” 1-5/8” 3-1/2” 2-1/8” Ø9/16” Ø9/16” COLOR OPTIONS SILV 9005 YEAR 2 WARRANTY ALU QUICK-FIX 12V AC/DC IP 54 TRICONE Design led-lighting for gates Plug & Play design LED lighting for your fences & gates. Gives your gate an aesthetically pleasing look with minimal power consumption! The Quick-Fix provides a fast and strong fixing on your fencing. ORDER CODE TRICONE Design LED lighting for gates with Quick-Fix DVK-HD P. 59 DVK P. 58 2005 P. 60 PB-1 P. 58 CABLE GUIDING AC-TRANS-12V-25W P. 60 DC-POWER-12V-20W P. 61 DC-ACCESS-12V-20W P. 60 RECOMMENDED POWER SUPPLIES SPECIFICATIONS • Fast and easy installation with Quick-Fix • Aluminum housing with plastic (POM) cable guiding • 3 White High-Flux LED Lights, color temperature: 5700K - 6500K • ± 140° beam angle • Life expectancy: 50,000 hours • 300 lux (illuminance) • Power: ± 1W (with 12V DC) • 12V AC or DC (max. 18V DC or peak AC) • Minimum power consumption and long lasting performance • Resin encapsulated print circuit board for weather resistance • Power up to 20 Tricone with 1 Locinox AC transformer or up to 15 with the DC power • IP54
2 3 1 1 Full concept for swing gates Surface mounted magnetic locks 1. MAGMAG High quality surface mounted magnetic lock with guaranteed holding force and long durability. 500h salt spray resistant. 2. N-LINE-MAG Aesthetic, adjustable and powder coated finishing profile for swing gates preventing people to stumble against protruding parts. 3. 3006PULL Elegant powder coated handle for easy opening and closing of the gate. • Save time and order the all-in-one N-LINE-MAG KIT • Add access control to your gate with the strong, frost-free and watertight SLIMSTONE-2 keypad • Make your gate self-closing with the aesthetic MAMMOTH gate closer TIP Surface-mounted magnetic locks are designed to provide a firm, silent closure and offer the possibility to be opened from a distance. With an extremely strong holding force and innovative dual layer coating, magnetic locks are highly resistant to intensive use and various weather influences - ideal for public applications. 46
47 AUTOMATION & ELECTRONICS YEAR 2 WARRANTY ALU CYCLES 500 K 12V DC 24V DC 7/8” 7/8” 4” 1-3/4” Ø7/16” (2x) 4” 1-9/16” 5-1/2” 9-3/16” 7/8” 9-3/16” 8-9/16” 2-11/16” Ø9/16” (3x) 3-7/8” 7/8” 2-3/4” 5-1/2” MAG3000 MAG6000 5-1/8” 2” Ø7/16” (2x) 4” 1-9/16” 5-1/2” 9-9/16” 7/8” 9-9/16” 8-15/16” 3-3/4” 4-5/8” 7/8” 5-1/2”2-3/4” Ø9/16” (3x) N-LINE-MAG-3000 P. 49 PB-1 P. 58 DC-POWER-24V-25W P. 61 DVK-HD P. 59 RECOMMENDED PRODUCTS COLOR OPTIONS SILV 9005 MAG Surface mounted electromagnetic lock with integrated pull/push handles The MAG is a bolt-on electromagnetic lock for powered access control. Available in 2 versions; the MAG3000 has up to 660 lbs. and the MAG6000 which has up to 1320 lbs. of pull force resistance. The aluminum powder coated housing with integrated design handles gives your access control gate that extra elegant touch. Stop losing precious time with welding boxes; drilling just 7 holes does the job – our patented Quick-Fix bolts help you install quickly and easily. A two-layer, protective coating guarantees that our electromagnetic locks are ready for years of worry-free use in the outside elements. ORDER CODES MAG3000 For square posts and gate profiles of 1-9/16" till 3-1/8", 660 lbs pulling force MAG6000 For square posts and gate profiles of 1-9/16" till 3-1/8", 1320 lbs pulling force SPECIFICATIONS • 500h salt spray resistant! SGS Certified (ISO 9227) • Guaranteed holding force tested on every magnetic lock • With Quick-Fix fixing • Weatherproof aluminum housing designed for exterior use • Anti-residual magnetism kick-off system • Raised edge on the magnet housing makes it impossible to put a crowbar between the magnet and the armature plate • Voltage: 12V / 24V DC • Current MAG3000: 500 mA / 12 V or 250 mA / 24 V • Current MAG6000: 460 mA /12 V or 230 mA / 24 V • IP68 rated - Extremely resistant to water and dust
48 AUTOMATION & ELECTRONICS YEAR 2 WARRANTY ALU CYCLES 500 K 12V DC 24V DC MAGMAG6000 7/8” MAGMAG3000 7/8” 1-7/16” 2-1/4” Ø5/8” (2x) 9-3/16” 5-1/2” 7/8” 1-3/4” 3-1/4” Ø5/8” (2x) 9-9/16” 5-1/2” 7/8” 8-9/16” 2-11/16” 3-7/8” 7/8” 2-3/4” 5-1/2” 8-15/16” 3-3/4” 4-5/8” 7/8” 5-1/2” 2-3/4” Ø9/16” (3x) Ø9/16” (3x) N-LINE-MAG-3000 P. 49 PB-1 P. 58 DC-POWER-24V-25W P. 61 DVK-HD P. 59 RECOMMENDED PRODUCTS COLOR OPTIONS SILV 9005 MAGMAG Surface mounted electromagnetic lock without integrated handles Screw-on magnetic lock without handle. Available in 2 versions. MAGMAG3000 with 660 lbs and MAGMAG6000 with 1320 lbs of pulling force. The aluminum powder coated housing equipped with the unique Quick-Fix fixations ensures a fast and nicely finished mounting. Eliminate time-consuming welding; drilling 5 holes is enough to fix the lock. A twolayer, protective coating guarantees that our electromagnetic locks are ready for years of worry free use outside. ORDER CODES MAGMAG3000 For square posts and gate profiles of 1-9/16" till 3-1/8", 660 lbs pulling force MAGMAG6000 For square posts and gate profiles of 1-9/16" till 3-1/8", 1320 lbs pulling force SPECIFICATIONS • 500h salt spray resistant! SGS Certified (ISO 9227) • Guaranteed holding force tested on every magnetic lock • Special two-layer protective coating developed for outdoor use • Weatherproof aluminum housing designed for exterior use • Anti-residual magnetism kick-off system • Raised edge on the magnet housing makes it impossible to put a crowbar between the magnet and the armature plate • IP68 rated - Extremely resistant to water and dust • Current MAGMAG3000: 500 mA / 12 V or 250 mA / 24 V • Current MAGMAG6000: 460 mA / 12 V or 230 mA / 24 V • Voltage: 12V / 24V DC
49 AUTOMATION & ELECTRONICS ORDER CODE N-LINE-MAG-3000 Aluminium finishing profile for MAG3000 & MAGMAG3000 RECOMMENDED MAGNETIC LOCKS MAG3000 P. 47 MAGMAG3000 P. 48 YEAR 2 WARRANTY ALU QUICK-FIX 2-11/16” 3x 1x 78-3/4” 3-13/16” COLOR OPTIONS SILV 9005 N-LINE-MAG Profile for MAG3000 and MAGMAG3000 magnetic locks Adjustable, powder coated aluminum design profile for aesthetic closing of the gaps between MAG3000 or MAGMAG3000 magnetic locks. To be fixed to the post. Prevents passersby to bump into the protruding parts of the magnetic lock. SPECIFICATIONS • Profile lengh: 78-3/4" • Delivered with self-drilling screws, compatible with Quick-Fix • 2 plastic cover caps and 6 in-between caps included • Separate adaptor needed with use of 3006PULL handle, delivered with 3006PULL
50 AUTOMATION & ELECTRONICS
51 AUTOMATION & ELECTRONICS N-LINE-MAG-3000 P. 49 KIT INCLUDES MAGMAG3000 P. 48 3006PULL P. 186 8-9/16” 2-11/16” 3-7/8” Ø9/16” (3x) 7/8” 2-3/4” 5-1/2” 1-7/16” 2-1/4” Ø9/16” (2x) 9-3/16” 5-1/2” 7/8” 1-1/2” 6-7/8” 4” - 2-1/16” - 4-3/16” - 2-1/16” - 4-3/16” A A B B C C D D COLOR OPTIONS SILV 9005 YEAR 2 WARRANTY ALU 12V DC 24V DC N-LINE-MAG-KIT-3000 Set with N-LINE MAG profile, 2x MAGMAG3000, 3006PULL Set with N-LINE MAG profile and 2x MAGMAG3000 and 3006PULL handle. 3006PULL handle is included to finish your gate. Aesthetic solution which prevents passersby to stumble against the parts of the magnetic lock. ORDER CODE N-LINE-MAG-KIT-3000 Set with N-LINE MAG profile and 2x MAGMAG3000 and 3006PULL handle SPECIFICATIONS • Adjustable aluminum design profile to mount above, below and in between the magnets • Profile lengh: 78-3/4" • Delivered with self-drilling screws, compatible with Quick-Fix • 2 plastic cover caps and 6 in-between caps included • Aluminum 3006PULL handle included • Delivered with 2x MAGMAG3000 • Voltage: 12V / 24V DC • Current: 500mA / 12V or 360mA / 24V
2 3 1 1 Built-in magnetic locks Full concept for sliding or swing gates 1. MAGUNIT High quality surface mounted magnetic lock with guaranteed holding force and long durability. 500h salt spray resistant. 2. N-LINE-B-MAG Aesthetic, adjustable and powder coated finishing profile for sliding or swing gates preventing people to stumble against protruding parts. 3. 3006PULL Elegant powder coated handle for easy opening and closing of the gate. • Save time and order the all-in-one N-LINE-B-MAG KIT • Add access control to your gate with the strong, frost-free and watertight SLIMSTONE-2 keypad • Make your gate self-closing with the powerful VERTICLOSE-2 gate closer TIP Built-in magnetic locks provide a discreet and secure solution for various gate situations and add the value of integrating with access control. With their extreme holding force and dual layer coating, these magnetic locks deliver reliable performance and withstand harsh weather conditions. 52
53 AUTOMATION & ELECTRONICS COLOR OPTIONS SILV 9005 9-7/8” 1-3/8” 1/4” 3-1/4” 2-3/4” 11-3/8” 9-7/8” (4x) Ø 9/16” 2” 10-7/8” 8-7/8” 1-5/8” 7/8” DVK-HD P. 59 PB-1 P. 58 DC-POWER-12V-20W P. 61 DC-ACCESS-12V-20W P. 60 SLIMSTONE-2 P. 38 DC-POWER-24V-25W P. 61 RECOMMENDED PRODUCTS YEAR 2 WARRANTY ALU CYCLES 500 K QUICK-FIX 12V DC 24V DC B-MAG Built-in electro-magnetic lock for swing gates Clean lines and security are assured with this magnetic lock’s installation. It’s installed right into the latching post. Our patented Quick-Fix fasteners and powder coating means it will hold up to the most extreme weather conditions. The rubber bumpers prevent shaking or damage to the gate and its hardware in case of harsh handling. The flexible assembly of the armature plate guarantees a solid latch connection even if the gate isn’t perfectly aligned. ORDER CODE B-MAG Integrated magnet and bolt-on anchorplate for swing gates SPECIFICATIONS • Guaranteed holding force tested on every magnetic lock • Minimal pulling force: 2500N (600 lbs) • 500h salt spray resistant! SGS Certified (ISO 9227) • Special two-layer protective coating developed for outdoor use • Anti-residual magnetism kick-off system • Current: 460mA / 12V or 230mA / 24V • Voltage: 12V / 24V DC • IP68 rated - Extremely resistant to water and dust
54 AUTOMATION & ELECTRONICS YEAR 2 WARRANTY ALU CYCLES 500 K QUICK-FIX 12V DC 24V DC 10-7/8” 2” 1-3/8” 7/8” 1-5/8” (4x) Ø9/16” 1/4” N-LINE-B-MAG P. 55 N-LINE-S-MAG P. 55 REQUIRED PRODUCTS SPECIFICATIONS MAGUNIT2500 Set with magnet and anchor plate for N-LINE (B or S)-MAG profiles Set with a MAG and anchor plate along with fittings for use with a N-LINE-B-MAG or N-LINE-S-MAG, 1 or more MAGUNITs can be mounted in the N-LINE profile. ORDER CODE MAGUNIT2500 Magnet and anchorplate for N-LINE-B-MAG and N-LINE-S-MAG profiles • Guaranteed holding force tested on every magnetic lock • 500h salt spray resistant! SGS Certified (ISO 9227) • Special two-layer protective coating developed for outdoor use • Anti-residual magnetism kick-off system • Current: 460mA / 12V or 230mA / 24V • Voltage: 12V / 24V DC • Minimal pulling force: 2500N (600 lbs) • IP68 rated - Extremely resistant to water and dust
55 AUTOMATION & ELECTRONICS COLOR OPTIONS SILV 9005 ORDER CODE N-LINE-B-MAG Aluminum finishing profile for MAGUNIT-2500 YEAR 2 WARRANTY ALU QUICK-FIX MAGUNIT2500 P. 54 COMPATIBLE MAGNET 2-13/16” 3-3/16” 78-3/4” 78-3/4” N-LINE-B-MAG Aluminum finishing profile for swing gates to combine with MAGUNIT-2500 Adjustable, powder coated aluminum design profile for aesthetic closing of swing gates along with 1 or more MAGUNIT-2500. Thanks to the integrated magnet and the armature plate, which are both integrated in the design profile, a safe and complete solution without any protruding components is guaranteed. SPECIFICATIONS • Profile lengh: 78-3/4" • Fast and easy fixation with Quick-Fix bolts • Powder coated aluminum housing • Specially designed for exterior use COLOR OPTIONS SILV 9005 ORDER CODE N-LINE-S-MAG Aluminum finishing profile for MAGUNIT-2500 YEAR 2 WARRANTY ALU QUICK-FIX MAGUNIT2500 P. 54 COMPATIBLE MAGNET 2-7/16” 1-1/4” 78-3/4” 78-3/4” N-LINE-S-MAG Aluminum finishing profile for sliding gates to combine with MAGUNIT Adjustable, powder coated aluminum design profile for aesthetic closing of sliding gates along with 1 or more MAGUNIT-2500. Thanks to the integrated magnet and the armature plate, which are both integrated in the design profile, a safe and complete solution without any protruding components is guaranteed. SPECIFICATIONS • Profile lengh: 78-3/4" • Fast and easy fixation with Quick-Fix bolts • Powder coated aluminum housing • Specially designed for exterior use
